NEW CID2 320W 24V MONOCRYSTALLINE SOLAR PANEL-Q

NEW CID2 320W 24V MONOCRYSTALLINE SOLAR PANEL-Q

SKU:
ST-320Q-24CID2
72 CELL

MONOCRYSTALLINE MODULE

320W

POWER OUTPUT

23.7%

MODULE EFFICIENCY

0~±3%

POSITIVE TOLERANCE

Add To Quote

  • Nominal 24V DC for standard output.
  • Outstanding low-light performance.
  • Heavy-duty anodized frames.
  • High transparent low-iron, tempered glass.
  • Designed to withstand high wind pressures, hail and heavy snow.
  • Quality aesthetic appearance.
  • Electrical Characteristics
  • Module Type ST-320Q-24CID2(-QC)
  • Maximum power (Pmax) 320W
  • Voltage at Pmax (Vmp) 40.02V
  • Current at Pmax (Imp) 7.62A
  • Open-circuit voltage (Voc) 47.76V
  • Short-circuit current (Isc) 8.01A
  • Module Efficiency 23.7%
    • *STC: Irradiance 1000W/m2 , AM1.5 spectrum, module temperature 25°C
  • Rating Characteristics
  • Operating temperature -40°C to 65°C
  • Maximum system voltage 600V/1000V DC
  • Power tolerance 0~±3%
  • Module Fire Performace Type 1 (for US)
  • Fire Resistance Rating Class C (For Canada)
  • PV module application class Class A
  • Temperature code rating T3C
    • *NOCT: Nominal operating cell temperature (the data is only for reference)
  • Specifications
  • Cells Monocrystalline silicon solar cell
  • No. of cell and connections 72(6x12)
  • Module dimension 53.15in. x 44.61in. x 1.57in. [1350mm x 1130mm x 40mm]
  • Weight 37.73lbs[17.11kg]
  • Temperature Characteristics
  • Temperature coefficient of Voc -(80±10)mV/°C
  • Temperature coefficient of Isc (0.065±0.015)%/°C
  • Temperature coefficient of power -(0.5±0.05)%/°C
  • NOCT (Air 20°C; Sun 0.8kW/m2 wind 1m/s) 47±2°C
Download
Download

*Limited warranty: 2-year limited warranty of materials and workmanship; 10-year limited warranty of 90% power output; 25-year limited warranty of 80% power output. For detail, please view full Warranty & Policy page
